As with ALL Valentini Power Harrows, the Leopard Series Is Quick-Hitch Compatible, and has been providing Excellent Soil Conditioning & Seed Bed Preparation in all types of soils - without inverting the soil, leaving nutrients on the top layer, leaving weed seeds deep & dormant, and not inverting moist substructure soils, preventing unwanted loss of moisture! The results have been proven in applications varying from Agricultural Use, to Construction Applications, to Landscaping Services, and in some of the most unconventional settings, Valentini has proven to have Bullet Proof Reliability, while producing Excellent Results in one pass! Whether your ground conditions have Standing Vegetation, or Imbedded Residue, Rocks, Stones or Hard Dirt Clods, expect to get the results you want with Valentini Power Harrows.
STANDARD FEATURES:
Quick Hitch Compatible, Cat 2, 3-Point Hitch.
1000RPM Large Sump Gearbox.
2 Way Cylinders for Hydraulic Folding & Opening of Power Harrow Sections.
Two Blades Per Rotor.
9" Spacing Between Rotors Provides Highest Population of Blades.
Heated Treated, Ulta-Hardened Central & Side Gears, and Blade Holders.
The Standard Leveling Bar Makes Valentini Power Harrows Excellent For Pasture Renovation By Producing Level & Conditioned Seed Bed Soils. It Also Makes It A Versatile PTO Powered Tool For Rough & Finish Grading, Filling Washouts, Conditioning Dirt Race Tracks, Conditioning Equestrian Paths & Paddocks, Fire Breaks & Dirt Trails, And Much, Much More!
QUICK HITCH COMPATIBILITY
Another Standard Feature!
ACCESSORIES
REAR ROLLERS
Provides Superior Working Depth Adjustment & Soil Conditioning.
Available with Manual or Hydraulic Adjustment.
Use the Hydraulic Adjustment Option & Control Working Depth Adjustment From Your Tractors Operator Station On-The-Fly!
LEOPARD SERIES POWER HARROW SPECIFICATIONS
MODEL
3200
3600
4000
4600
5000
Tractor Horsepower (PTO)
100 - 180HP
110 - 180HP
120 - 180HP
140 - 180HP
150 - 180HP
PTO Speed
1000RPM
Rotor
298RPM
Working Width
129"
146"
167"
181"
198"
Overall Width
131"
149"
166"
183"
201"
Number of Blades
28
32
36
40
44
Working Depth
11"
Weight with Packer Roller
3,206 lbs.
3,637 lbs.
4,068 lbs.
4,497 lbs.
4,928 lbs.
Weights are Less Pallets, Crates & PTO Shaft.
LEOPARD SERIES POWER HARROW SPECIFICATIONS
MODEL
3200
3600
4000
4600
5000
Tractor Horsepower (PTO)
100 - 180HP
110 - 180HP
120 - 180HP
140 - 180HP
150 - 180HP
PTO Speed
1000RPM
Rotor
298RPM
Working Width
129"
146"
167"
181"
198"
Overall Width
131"
149"
166"
183"
201"
Number of Blades
28
32
36
40
44
Working Depth
11"
Weight with Packer Roller
3,206 lbs.
3,637 lbs.
4,068 lbs.
4,497 lbs.
4,928 lbs.
Weights are Less Pallets, Crates & PTO Shaft.
Specifications & Designs Are Subject to Change Without Notice
